Anilox Service

Deep Cleaning, Rebuild & Spare parts for coating Units

Graphiconsult has more than 20 years of experience in service and maintenance of anilox rollers, sleeves and chamber parts. I currently support some of the largest packaging, metal, label and sheetfed printing companies in EU.

If you need deep cleaning of your rollers or sleeves, we can do it in your machine without the need to take out the rollers or sleeves. We also rebuild your rollers or sleeves if they need new engraving, NEW rollers or sleeves "ready to run" also no problem.

Before & After Deep Cleaning

Protecting your Anilox rollers

Covers with color system in relation to volume (cm3/m2)

Standard & customized covers

We produce our own covers in all standard dimensions and for all rollers. If you have a service agreement with us for maintenance and renovation of anilox rollers, when ordering a cover, specially made magnetic labels are included that can follow the individual rollers or sleeves in production, as well as roller cards that come with each cover.

Chamber & Blades

Make sure the blades & sealings are correct installed

Blades Positions and how to maximize blade & end seal performance

Two different types of blades are used in a typical chamber system "AR" (Metering Blade) carries out the final scraping of the Anilox roller before the ink or varnish is transported to the roller or plate "LR" (Containment Blade) as the name indicates, it contains the Ink or the varnish inside the chamber.

These blades are wearing parts and must be changed regularly due to wear and tear. The wear depends on elements such as speed, the surface of the anilox roller as well as pigmentation in the Ink or varnish etc

Clarification of blade position which blade is Working blade or containment blade depends on the structure of each chamber and which direction the anilox roller turns. The diagram below shows the correct position of "AR" in relation to the rotation of the anilox roller in terms of "clockwise" (MEU) and "counter-clockwise" (MOU). "LR" is placed opposite "AR"

Make sure the blades & sealings are correct installed

How to get startet

Would you rather Deep Clean your self? No Problem

1. Get Bottle, Brush & Sponge

You can get your starter set through many partners World wide, contact us to find a dealer in your area. If you are a dealer you can also contact us below for more info on our products.

2. Clean the Anilox Roller

Apply with sponge and keep the roller moist with PGC for at least 10 minutes, brush after 10 minutes with our special steel brush to get to the bottom of the cells, finally clean with water

DOWNLOAD Instruction.pdf

3. Meassure roller if possible

If you have the opportunity to control the roller at 2-500 times magnification this should be done. alternatively check with strips from Capatch, these can also be ordered with the start package
